(Discontinued) Raspberry Pi Compute Module 3 1GB RAM, 4GB Emmc

The CM3 Compute Module contains the guts of a Raspberry Pi 3 (the BCM2837 processor and 1GB RAM) as well as an optional 4GB eMMC Flash device (which is the equivalent of the SD card in the Pi). The Pi 3 has a processor speed of 1.2GHz and runs at roughly 10 times the speed of the Pi 1 due to its quad-core CPU. This CM3 Compute Module is all integrated on to a small 67.6mm x 31mm board which fits into a standard DDR2 SODIMM connector (the same type of connector as used for laptop memory).

The Flash memory is connected directly to the processor on the board, but the remaining processor interfaces are available to the user via the connector pins. You get the full flexibility of the BCM2837 SoC (which means that many more GPIOs and interfaces are available as compared to the Raspberry Pi), and designing the Module into a custom system should be relatively straightforward as we’ve put all the tricky bits onto the Module itself.

Features:

1. The module is based on the Broadcom BCM2837 processor, which includes a 64-bit ARM Cortex-A53 CPU clocked at 1.2GHz.
2. The module includes 1GB of LPDDR2 RAM and a 4GB eMMC flash memory module for storage.
3. The CM3 module measures just 67.6mm x 31mm and has a standard DDR2 SODIMM connector.
4. The module includes two 100-pin expansion headers that provide access to a wide range of I/O interfaces, including USB, Ethernet, SPI, I2C, and GPIO.
5. The CM3 is designed to operate in a range of environments
6. The CM3 is a flexible computing platform that offers a great balance of performance, power consumption, and ease of integration, making it a popular choice for a wide range of embedded systems and other applications.

Package Includes:

1 x (Discontinued) Raspberry Pi Compute Module 3 1GB RAM, 4GB Emmc

1 Year Warranty

This item is covered with a supplier warranty of 1 year from the time of delivery against manufacturing defects only. In case of manufacturing defects or issues, we will replace the part after warranty confirmation by our technical team, but we won’t offer refunds or replace the entire product.

What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
