Geekworm X1011 PCIe to Four M.2 NVMe SSD Board for Raspberry Pi 5

The X1011 four M.2 NVMe SSD shield, designed to provide a mass-capacity storage and high-speed storage solution for your Raspberry Pi 5. Its sleek and compact design enables easy attachment of four full-size M.2 2280 SSDs to your Raspberry Pi 5. With its PCIe 2.0 interface, you can experience data transfer rates of up to 5Gbps, allowing you to effortlessly transfer large amounts of data within seconds.

The X1011 connects to the underside of the Raspberry Pi 5, eliminating the need for a passthrough for the GPIO. This means you can use your favorite HATs while also utilizing this expansion board. Moreover, the X1011 offers versatile power options – it can draw power from the Raspberry Pi5 through pogo pins using a USB-C power supply, or alternatively, power the Raspberry Pi5 from the X1011 using a DC power adapter via the onboard DC power jack, streamlining the power supply process to a single source.

The X1011 is an ideal storage solution for creating a home media center or building a network-attached storage (NAS) system. It allows you to store and stream your own videos, music, and digital photos within your home or even remotely across the world.

Note:   Raspberry Pi Board is Not Included.

Features:

1. Compatible with Raspberry Pi 5B only
2. Support FOUR M.2 NVMe SSDs
3. Support M.2 NVMe SSD with 2280/2260/2242/2230 length
4. PCB Size: 109mm x 87.2mm
5. Provides speedy data transfer with PCIe 2.0 5Gbps
6. Powering via both pogo pins & FFC or DC power jack, ensuring sufficient power supply without any worries
7. LED indicators in blue display power and drive status
8. Features an integrated high-performance PCIe packet switch
9. Equipped with high-efficiency DC/DC step-down converter, delivering a maximum of 10A to power your SSDs
10. Designed to be attached on bottom, allows using your favorite HATs alongside it
11. Compatible with the HAT+ STANDBY power state, automatically turning off when the Pi 5 shuts down.
12. Compatible with the official Raspberry Pi 5 active cooler or Argon THRML 30mm Active Cooler or third party cooler without affecting cooling performance

Package Includes:

1 x Geekworm X1011 PCIe to Four M.2 NVMe SSD Board for Raspberry Pi 5

6 Months Warranty

This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Replacement will be done against manufacturing defects.

What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
